—— Professional Grade Downhill Hubs ——
Engineered for Downhill dominance with Super Boost spacing, J-Bend steel spokes, and 6-Bolt disc mount. This premium M510 hub system is built to withstand the harshest Downhill terrain and deliver uncompromising performance.
01 / Front Hub Specifications
Optimized front hub with 20×110mm Thru-Axle, J-Bend steel spokes, and 6-Bolt disc mount for Downhill resilience.
The M510 front hub's 20×110 Super Boost spacing and J-Bend steel spoke design create a front wheel system that stands up to the most aggressive Downhill riding conditions.
02 / Rear Hub Performance
Advanced rear hub with 12×157mm Super Boost spacing, J-Bend steel spokes, and 6-Bolt disc mount for Downhill power.
The M510 rear hub's 12×157 Super Boost spacing and 6-Bolt disc mount combine to create a durable, high-performance hub that excels in the most demanding Downhill environments.
Complete parameters for M510 high-performance Downhill MTB hubs
Built for Downhill riding with J-Bend steel spokes and universal 6-Bolt disc brake compatibility, delivering reliable braking performance even in wet, muddy conditions.
Supports Shimano HG, XD, MS freehub bodies, adaptable to all mainstream DH drivetrain systems.
| Specification | Front | Rear |
|---|---|---|
| Type | Downhill MTB | |
| Spoke system | J-Bend | |
| Matching spoke | Steel Spoke | |
| Spoke holes | 32H | 32H |
| Bearings | 2 × 6805 | 2 × 6903 + 2 × 15267 |
| Axle × OLD | 20 × 110mm | 12 × 157mm |
| Brake interface | 6-Bolt | |
| Freehub | — | HG / XD / MS |
| Driving system | — | PG Ratchet System |
| Weight | 501 ± 5g / set | |
The M510 DH Super Boost hub system combines 20×110/12×157mm Super Boost spacing, J-Bend steel spokes, and 6-Bolt disc compatibility to deliver unbeatable strength, stiffness, and reliability for serious Downhill riders. Contact our technical team to learn more about M510 hubs and find the perfect configuration for your bicycle.
